KSS
Solenoid Controlled Switch
User Manual - Original Language Version
The KSS solenoid controlled switch is designed to be part of a safety system and is used to isolate the power releasing a key
which is then used to gain access to a hazardous area via an access interlock such as the AI, AIE or Salus.
The KSS solenoid controlled switch is not designed for security purposes.
No hazardous substances were used in the manufacture of this product. The product can be disposed of in standard waste.
Usage
Installation
Back of panel units should be mounted to a at surface using suitable fasteners (please refer to drawing on page 4 for more
details). The lock face should be sealed to the panel for ingress protection.
Cables should be connected to the switch in accordance with the applicable wiring diagrams. Ensure that the unit is bonded for
earth continuity (see drawing on page 6 for more installation details).
IMPORTANT:
The interlock should be mounted using anti-tamper fasteners to prevent unauthorised removal.
The KSS range of solenoid controlled switches must be installed by a competent and qualied person who has read and
understood these instructions. Please retain this document in your technical le.
Maintenance
Periodic visual checks should be carried out by the site manager / safety ofcer.
Do not lubricate lock barrel with oil or grease, use CK Dry Powder Graphite if necessary.
In case of defects beeing detected please contact your nearest Castell Support Department for further actions.
Please see Contact section for contact details.
