PARTS LIST
11
LS-1700/LS-1700HD/TS-1700HD/LS-2000/LS-2000HD/TS-2000HD (03–01)
HANDLE GROUP
REF PART # DESCRIPTION QTY.
1 200823 DGRIP, HANDLE TUBE 2
2 607336 HANDLE, UPPER, BLUE 1
3 130204 CORD, 14/3X57”, BLACK 1
4 607338 HANDLE, LOWER, BLUE 1
5 603116 PIN, HANDLE PIVOT 1
6 140860 SCREW, SET 1
7 603107 LATCH, HANDLE 1
8 140003 WASHER, 1/4X1 4
9 607339 DECAL, LS-1700 1
607926 DECAL, LS-2000 1
607340 DECAL, LS-1700HD 1
607923 DECAL, LS-2000HD 1
607341 DECAL, TS-1700HD 1
607925 DECAL, TS-2000HD 1
10 603106 LEVER, HANDLE LATCH 1
11 140147 BUSHING 4
12 579210 WASHER, FLAT 3
13 578244000 WASHER,LOCK 4
14 578321000 SCREW, M6X1.0X16 6
REF PART # DESCRIPTION QTY.
15 579029 NUT, M6X1.0 2
16 606334 SPRING, HANDLE LATCH 1
17 604267 BRACKET, PIVOT UPPER 1
18 604268 BRACKET, PIVOT LOWER 1
19 578321000 SCREW, M6X10.0X16 4
20 578244000 WASHER, LOCK 2
21 606015 DKNOB, HANDLE LOCK 1
22 140037 DWASHER, NYLON 1
23 120619 DECAL, WARNING 1
24 140239 SCREW, 3/8DIAX1–3/4 1
25 603108 SPRING, SWITCH 1
26 603104 HOOK CORD HANDLE 1
27 578244000 WASHER, LOCK 1
28 200031444 SCREW, M6X1.0X30 1
29 604306 TUBE, FOLDING HANDLE 1
30 578729 DECAL, READ MANUAL 1
31 130141 BUSHING, STRAIN–RELIEF 1
