OPERATION
LS-1700/LS-1700HD/TS-1700HD/LS-2000/LS-2000HD/TS-2000HD (07–00)
7
TROUBLE SHOOTING
PROBLEM CAUSE SOLUTION
Machine does not Faulty power cord. Contact Service Center.
operate.
Tripped circuit breaker. Reset circuit breaker on machine.
Tripped building circuit breaker. Reset circuit breaker in building.
Faulty machine wiring. Contact Service Center.
Faulty trigger switch. Contact Service Center.
Faulty motor. Contact Service Center.
Capacitor burned out. (Single speed models) Contact Service Center.
Rectifier burned out. (Dual speed models) Contact Service Center.
Machine circuit Soiled Pad. Replace Pad.
breaker trips
continuously.
Improper pad/brush for application Change to proper pad/brush.
continuously.
Defective circuit breaker. Contact Service Center.
Worn motor brushes. (Dual Speed Model) Contact Service Center.
SPECIFICATIONS
MODEL LS-1700 LS-1700HD TS-1700HD LS-2000 LS-2000HD TS-2000HD
WIDTH
450 mm (17.75 in) 450 mm (17.75 in) 450 mm (17.75 in) 530 mm (20.75 in) 530 mm (20.75 in) 530 mm (20.75 in)
HEIGHT
1220 mm (48 in) 1220 mm (48 in) 1220 mm (48 in) 1220 mm (48 in) 1220 mm (48 in) 1220 mm (48 in)
LENGTH
550 mm (21.5 in) 550 mm (21.5 in) 550 mm (21.5 in) 600 mm (23.5 in) 600 mm (23.5 in) 600 mm (23.5 in)
FOLDED HEIGHT
440 mm (17.5 in) 440 mm (17.5 in) 440 mm (17.5 in) 520 mm (20.5 in) 520 mm (20.5 in) 520 mm (20.5 in)
FOLDED LENGTH
840 mm (33 in) 840 mm (33 in) 840 mm (33 in) 900 mm (35.5 in) 900 mm (35.5 in) 900 mm (35.5 in)
WEIGHT
40.8Kg (90 lbs) 43Kg (95 lbs) 41.7Kg (92 lbs) 42Kg (93 lbs)
44Kg (98 lbs) 43Kg (98 lbs)
DRIVE MOTOR
120V, 1 hp 12A,
60Hz
230V, .75kW, 7A,
50Hz
120V, 1.5 hp 12A,
60Hz
230V, 1.1kW, 7A,
50HZ
120V, 1.5 hp 12A,
60Hz
230V, 1.1kW, 7A,
50HZ
120V, 1 hp 12A,
60Hz
230V, .75kW, 7A,
50Hz
120V, 1.5 hp 12A,
60Hz
230V, 1.1kW, 7A,
50HZ
120V, 1.5 hp 12A,
60Hz
230V, 1.1kW, 7A,
60HZ
PAD/BRUSH SPEED
175 RPM
175 RPM 185/330 RPM
175 RPM
175 RPM 185/330 RPM
POWER CORD LGH
15 m (50 ft) 15 m (50 ft) 15 m (50 ft) 15 m (50 ft) 15 m (50 ft) 15 m (50 ft)
BRUSH PAD DIA.
430 mm (17 in) 430 mm (17 in) 430 mm (17 in) 510 mm (20 in) 510 mm (20 in) 510 mm (20 in)
DECIBEL RATING
AT OPERATOR’S
EAR, INDOORS ON
TILE FLOOR
<70dB(A) <70dB(A) 71dB(A) At Low
Speed
73dB(A) At High
Speed
<70dB(A) <70dB(A) 71dB(A) At Low
Speed
73dB(A) At High
Speed
