2nd - Second level of Set-up Menu
The following functions are located in a second menu level:
- PPU (push-pull unit)
- C-C (cooling unit cut-out)
- Ito (ignition time-out)
Changing to the second menu level (2nd)
- Choose the parameter “2nd”, as described in the sections
headed "Acessing the setup-menu"
- Press and hold the MEM button
- Press the Process button
- Release the MEM button
The power source is now in the second menu level (2nd) of the
set-up menu. The function “PPU” (Push-Pull Unit) is now
displayed.
Select function
- Select the required function with the Process button
- Set up the function as described in the following sections
Exit from the second menu level (2nd)
- Press the MEM button
N.B! Any changes only become active if you switch to a different
function or exit from the second menu level (2nd).
PPU... Push-Pull Unit (see the section headed “Push-Pull
Unit”)
C-C ... Cooling unit cut-out ... ON / OFF / Aut
Factory setting: Aut (automatic)
Ito ... Ignition Time-Out ... OFF / 5 ... 100 mm length of wire is
fed until the safety cut-out is triggered, factory setting:
OFF
Special 2-step mode for robot interface
N.B.! The parameters for the “Special 2-step mode for robot
interface” are available when a robot interface or a field-bus
coupler for robot control is connected up to the LocalNet.
I-S ... Starting ... 0 - 200 % of the welding current
Factory setting: 135 %
SL ... Slope ... 0.1 - 9.9 s, Factory setting: 1.0 s
I-E ... End current ... 0 - 200 % of the welding current
Factory setting: 50 %
t-S ... Duration of starting current ... OFF / 0.1 ... 9.9 s
Factory setting: OFF
t-E ... Duration of end current ... OFF / 0.1 ... 9.9 s
Factory setting: OFF
N.B.! The above parameters are illustrated by a graph in the
section headed “MIG/MAG welding”.
Parameters for "Aluminium 4-step" mode
I-S ... Starting current ... 0 - 200 % of welding current
Factory setting: 135 %
SL ... Slope ... 0.1 - 9.9 s, Factory setting: 1 s.
I-E ... End current ... 0 - 200 % of welding current
Factory setting: 50 %
Parameters for "Spot welding" mode
SPt ... Spot-welding time ... 0,1 - 5,0s, Factory setting: 1.0s
