(1)If the cable is damaged or needs replacing, this should be done by an aft
er-sales
technician using the proper tools, so as to avoid any accidents.
(2)If the appliance is being connected directly to the mains supply , an omnipolar circuit
breaker must be installed with a minimum gap of 3 mm between the contacts.
(3)The installer must ensure that the correct electrical connection has been made and that
it complies with safety regulations.
(4)The cable must not be bent or compressed.
(5)The cable must be checked regularly and only replaced by a properly qualified person.
z Diagram of induction hob:
Power regulating key
Control panel Air vent
Ceramic plate
Air entry
Heating zone selection key ON/OFF Timer key
System key
- 5 -
Means for all-pole disconnection must be incorporated in the fixed wiring in
accordance with the wiring rules
Control panel
Air vent
Ceramic plate
Air entry
1
2
3
4
220-240V~
32A
