This range hood is factory set for venting through the roof or wall.
Vent work can terminate either through the roof or wall. To vent through a wall, a 90° elbow
is needed.
NEVER exhaust air or terminate duct work into spaces between walls, crawl spaces, ceiling,
attics or garages. All exhaust must be ducted to the outside.
Use metal/aluminum duct work only.
Fasten all connections with sheet metal screws and tape all joints with certified duct tape or
equivalent.
Use caulking to seal exterior wall or roof opening around the cap.
Option 2:
Vertical Roof VentingHorizontal Wall Venting
Option 1:
•
•
IMPORTANT:
•
•
•
•
Pg 7
Venting Methods
Side Wall Cap
Roof Cap
