Cavius 2107-001 - Recess Kit Final Assembly

15
INSERT RECESS KIT
MOUNTING BASE INTO
THE HOLE AND SECURE
WITH SCREWS
PLACE COVER RING
AROUND THE RECESS
KIT MOUNTING BASE
CLICK THE SMOKE
ALARM FIRMLY INTO
THE BASE TO ACTIVATE
2. Using your hole saw
(81mm-85mm),cuta
hole into the surface.
CAUTION: Ensure
there is no wiring or any
electrical equipment
behind the surface you
are drilling your hole into.
