Cayin MINI-CD MK2 - Technical Specifications; Audio and Digital Output Specifications; Physical and Power Specifications; Front Panel Controls Overview

Specification:
 Output level: 2.0V.5dB
 Frequency response: 20Hz~20kHz (.5dB)
 Distortion and noise: ≤0.007% (1kHz)
 S/N ratio: ≥90dB (20-20KHz, A-weighted)
 Dynamic range: ≥90dB (20-20KHz, A-weighted)
 Crosstalk（串音）: ≥77dB
 Digital output: S/Pdif: RCA coaxial, 0.5Vp-p@75Ω, output impedance 75Ω
I²S: HDMI-A interface
 Dimensions: 240mmx213mmx58mm (WxDxH)
 Net weight: ≈2.0kg
 Maximum power consumption: 12W
 Disc support: 12cm CD disc
Front Panel Functional Description
1
Power On/Off:
Turn on and off the CD player.
2
Disc Tray:
Insert and eject CD disc.
3
VFD Display:
Display various working status.
4
Function Indicator:
a. Indicator consistently on: SRC function in regular operation
b. Indicator flashing: It is at mute state
5
Remote Sensor Window:
Receive commands from infrared remote control.
6
Stop button/Insert/Eject:
During play or pause mode, press the button to stop playing.
Press it again to eject the disc, press it a third time to insert the disc.
7
Skip (previous) Button/Fast-Reverse Button: Refer to "5. Track search" in "Basic
Operation", hold the button depressed for fast-reverse operation.
