walnut LOW DRESSER
Made in Vietnam - r04 Page 3 of 5
5
6
Insert 6 cam screws into top panel as shown.
Secure, but do not over tighten, the cam screws
with a screwdriver.
7
8
A. Attach left small drawer side to small
drawer front with 2 screws as shown. Secure,
but do not over tighten, screws with a screwdriver.
B. Insert drawer bottom into grooves of small
drawer front and side as shown.
A. Attach left small drawer side to small drawer
back with 2 screws as shown.
B. Attach right small drawer side to small
drawer front and back with 4 screws as shown.
A
B
B
NOTE: Do not
over tighten
the screws
A
NOTE: Do not
over tighten
the cam screws
With the assistance of another adult, fit dowels of
assembly into top panel as shown. Using a
screwdriver, turn each cam clockwise until it
securely engages each cam screw.
Customer Service 800.606.6252 | Latest instructions available at www.cb2.com
