MANUFACTURER“PROGRAMMING”MENU
Toaccessthemanufacturer’sprogrammingmenu,pressandkeeppressedfor3secondsthebutton“rif.3”,
untilthepanelbeeps;thenpressthebutton“rif.2”.
Pressanybuttonofthe7toaccessthemainparametersettingmenus.
Toconfirmchangestoparametersandreturntotheprecedingdisplay,press“SAVE”.
Toreturntotheprecedingdisplaywithoutsavingthechanges,pressthe“ARROW”button.
Toexitthesettingsmenu,press“EXIT”,orwaitfor30secondswithoutpressinganybutton.
1) Buttonfor“HOUR”menu(seeusers“SETTING”menu).
2) Buttonfor“PANEL SET-UP”menu(seeusers“SETTING”menu).
3) Buttonfor“SYSTEMSET-UP”menu:
TEMPERATURES
-INTERNAL:Adjustinsidetemperaturesensor.
-EXTERNAL:Adjustoutsidetemperaturesensor.
BATTERIES
-CARBATTERY
-VOLTAGE:adjustingtheenginebatteryvoltage(max±1V).
-CHASSIS:Carbatteryvoltageset(12V/24V).
-LEISUREBATTERY
-VOLTAGE:adjustingtheservicebatteryvoltage(max±1V).
-O AMPMETER:adjustingtheampmeter«0»value(A).
TANKS
-DRINK
-VISUALIZATION:measureunitset(%5/%10/LITERS/3/3).
-CAPACITY:settingthecapacity(50÷1050L).
-STATUS
- AUXTANK
-VISUALIZATION:measureunitset(%5/%10/LITERS/3/3).
-CAPACITY:settingthecapacity(50÷1050L).
-STATUS:activation/deactivationoftankcontrol(OFF/DRINK/WASTE).
-WASTE
-VISUALIZATION:measureunitset(%5/%10/LITERS/3/3).
-CAPACITY:settingthecapacity(50÷1050L).
-STATUS:activation/deactivationoftankcontrol(OFF/ON).
-SEWAGE
-VISUALIZATION:measureunitset(%5/%10/LITERS/3/3).
-CAPACITY .
-STATUS:activation/deactivationoftankcontrol (OFF/ON).
(deactivated).
(deactivated)
CONTROL TOUCHSCREENPANEL “PC770-SK”
1
2
3
7
6
5
4
