CBE Concorde PC770-SK - Protection Fuses

GB
ENGLISH
GB
29
1) 3A fuseforOUT D+simulatedexitprotection.
2) 20A fusetogivepowertotheRHauxiliaryexit,itdependsonthemain .
3) 20A fusetogivepowerto TVsockets,itdependsonthemain .
4) 20A fusefor“RES”auxiliaryexitpowersupply,whichisdirectlyconnectedtoleisurebattery(B2).
5) 20A fusefor“RES”auxiliaryexitpowersupply,whichisdirectlyconnectedtoleisurebattery(B2).
6) 25A fuseforradiosupply,whichisdirectlyconnectedtoleisurebattery(B2).
7) 10A fusetogivepowertoheating,itdependsonheating .
8) 20A fuseforalarmsystempowersupply,whichisdirectlyconnectedtoleisurebattery(B2).
9) 7,5A fuseforengine’sheatingpowersupply.
10) 3A fuseforcontrolpanelpowersupply.
11) 5A fuseforawninglightpowersupply,whichdependsontheawninglight andautomatically
switchesoffwhenengineison.
12) 25A fuseforelectricsteppowersupply,whichisconnecteddirectlytoleisurebattery(B2).
button
button
button
button
13) 7.5A fuseforpowersupplyofgasdevice,directlyconnectedtotheleisurebattery(B2).
14) 15A fuseforpowersupplyoflightsthroughpushbutton,itdependsonthemainbutton.
20 20 10 7.5 53
20 20 325 20
RES
15 25 25 1025
7.5 7.5 530 25
1
12
2 13
3 14
4 15
5
6 168 1810 20
7 179 1911 21
2
3
1
5
4
6
7
8
9
2
3
1
5
4
6
RH R E S
RES
M
123
456
789
101112
13
14
15
1
2
3
4
1
2
3
4
5
1
2
3
4
1
2
3
4
1
2
3
4
1
2
3
4
1 2
1 3
1
4
43
21
30
23
26
27
33
28
35
38
40 41
39
36
34
42
29
24
25
22
43 44
-
B
A C
1 3
31
1 4
37
1 2
32
“DS-560SK”DISTRIBUTIONBOARD
PROTECTIONFUSES
