CONNECTIONS
BLACK
“DS560-SK”DISTRIBUTIONBOX
Tobeconnectedtothe6poleconnector(ref.33)ofthedistributionbox
“DS560-SK”.
BUSCONNECTION(x2)
Tobeconnecttothebusmodules.
INTERNAL TEMPERATURE
Tobeconnectedtotheinternaltemperaturesensor.
EXTERNAL TEMPERATURE
Tobeconnectedtotheexternaltemperaturesensor.
SOFTWAREVERSION
Toseethesoftwareversiononthecontrolpanel,pressanybuttonduringtheswitch-ondisplay
2
3
4
5
1
2
1
2
INT
EXT
5 4
1
4
2
1
4
1
3
USBPORT
Onlyforsoftwareupdates.
