CBE Concorde PC770-SK - Bus Module Connections; Bus Node Connections

GB
ENGLISH
GB
31
1-2)“AK300/600”inverter
controlcleancontact
INVERTER
WHITE
30
ENGINEHEATING
WHITE
31
1)masse
2)-engineheatingbutton
3)+engineheatingbuttonled
OUTD+
RED
32
1-2)+exitOUT D+signal
CONTROL PANEL
BLACK
33
Toconnecttothe16poles
connectorofthecontrol
panel
Toconnecttothesewage
waterprobewithrods.
SEWAGEWATERTANK
BLACK
38
WASTEWATERTANK
39
Toconnecttothewaste
waterelectronicprobe.
AUXTANK
40
Toconnecttotheauxiliary
tankelectronicprobe.
BUSCONNECTION
BLACK
34
Busmodulesconnection
SIGNALS
RED
35
1)+OUT D+24V
2)+B1
3)+inputnetsignal.
SOLARREGULATOR
BLACK
36
1)N.C.
2)solarsignal
3)N.C.
4)N.C.
CONTROLS
WHITE
37
1)Lightbutton2
2)Invertercontrolbutton
3)Lightbutton1
4)masse
GREEN
RED
DRINKWATERTANK
41
Toconnecttothedrink
waterelectronicprobe.
WHITE
Massestobeconnectedto
theuser’snegativepole.
MASSE
WHITE
42
LEISUREBATTERY
43
Tobeconnectedtotheplus
poleofleisurebattery(B2).
MASSE
44
Tobeconnectedtothe
minuspoleofleisure
battery(B2)ortocar
chassis.
