HPS-2007
2
1. GENERAL
1.1 Product front view
a) Front panel
a.1) Front panel functions and indications
1 Remote control sensor 6 Menu
2 Video input 7 Channel UP
3 Standby 8 Volume UP
4 Audio input 9 Channel DOWN
5 Power On/Off 10 Volume DOWN
1.2 Product back view
a) Back panel
a.1) Back panel functions and indicatioins
1
Antenna input - UHF/ VHF ( 75 Ω )
2 Video input
3 Audio input Mono (L)
