CCE HPS-2007 - Definitions of the Registers

HPS-2007
23
3.2 Definitions of the registers
Description of service and factory registers
Register Name Range Description Default
Value
01 HSh 00 63 Horizontal shift 45
02 VSD 00 00 Vertical screen 0
03 VSl 00 63 Vertical slope 30
04 VAm 00 63 Vertical amplitude 44
05 VSh 00 63 Vertical shift 32
06 SC 00 63 S-correction 14
The registers bellow must be set to the default values.
Register Name Range Description Default
Value
10 TWBl 00 255 Timing of ‘wide blanking’ 88
11 PWLi 00 63 Peak white limiting 08
12 OSIF 00 63 Off-set IF demodulator 20
13 HzPl 00 63 Horizontal parallelogram 32
14 HBow 00 63 Horizontal bow 32
15 HSh 00 63 Horizontal shift 45
16 EW 00 63 EW width 34
17 PW 00 63 EW parabola/width 35
18 EWUC 00 63 EW upper corner parabola 35
19 EWLC 00 63 EW lower corner parabola 35
20 TC 00 63 EW trapezium 33
21 VSl 00 63 Vertical slope 30
22 VAm 00 63 Vertical amplitude 44
23 SC 00 63 S-correction 14
24 VSh 00 63 Vertical shift 32
25 VX 00 63 Vertical zoom 25
26 VOT 00 63 Vertical Offset 28
27 TAS 00 63 Text Area Start 13
28 OEA 00
127
Odd Even Alignment 60
29 BLOR 00 63 Black level offset R 32
30 BLOG 00 63 Black level offset G 32
31 WPR 00 63 White point R 32
32 WPG 00 63 White point G 32
33 WPB 00 63 White point B 32
34 PkFr 00 3 Peaking Frequency 1
35 YDl 00 15 Luminance delay time 10
36 AGC 00 63 AGC take-over 25
37 CDc0 00 15 Colour decoder 0 6
38 CDc1 00 7 Colour decoder 1 0
39 AVS0 00 127 AV-switch 0 64
40 AVS1 00 7 AV-switch 1 0
41 Syn0 00 127 Synchronisation 0 0
42 Syn1 00 63 Synchronisation 1 16
43 Defl 00
255
Deflection 16
44 VIF0 00 255 Vision IF 0 32
45 VIF1 00 255 Vision IF 1 2
46 SND0 00 255 Sound 0 10
47 CTL0 00 255 Control 0 0
48 CTL1 00
255
Control 1 0
49 SND1 00 255 Sound 1 0
50 FEA0 00 63 Features 0 0
51 FEA1 00 127 Features 1 0
52 BRI 00 63 Brightness 32
53 CON 00 63 Contrast 63
54 COL 00 63 Color 32
55 PEA 00 63 Peaking 45
