Technical instructions Mini Brio X15CA v1.0EN
www.ccei.ca
3
2. Technical features
Sizes Ø 47 mm (1-11/16in) / length 84mm (3-5/16in)
Installation Only in a threaded 1.5" niche ref. PF10R191 or PF10R192
Power supply 12 V ~ (AC) 50Hz/60Hz
Power consumed 12W maximum (according to colour)
Weight
Cable lenght Projector only Complete box
4,6m (15ft) 0,5kg (1,1lb) 1,2kg (2,6lb)
15,2m (50ft) 1,2kg (2,6lb) 1,9kg (4,2lb)
30,4m (100ft) 2,2kg (4,4lb) 2,9kg (6,4lb)
LED type
3 powerful RGB LEDs
Risk group 1 (low risk) according to IEC62471:2006
Protection index IP-68
Max. luminous flux According to colour/411 lm maxi (white)
Color control By BRIO-RC+ or by toggle switch
The projector must never be powered other than in water.
