PHENIX
Technical Manual v2.0
CCEI page 8
OXIDANT MENU
This menu is used to select the ORP regulation mode. To access the
different settings, simply press the  key.
The  and  keys are used to scroll through this menu. The different displays in
this menu are:
This screen allows you to choose the regulation mode. To do that, simply press the 
key and choose the regulation mode using the  and  keys.
The different possible regulation modes are as follows:
- REG: initiates the production of chlorine if the measured RedOx potential is less
than the set threshold.
- PRG: produces the programmed quantity of chlorine every day, whatever the
measurement.
- ON: to continuously produce without regulation. This mode can be used in case of
ORP sensor failure. Production remains dependent on the operation of the filtration
pump.
- OFF: to prevent the chlorinator injecting any chlorine. This mode can be used
during wintering for example.
To validate the mode, press the  key. To exit the programme without validating
the mode, press the

key.
This screen allows you to set the desired RedOx potential. To change this value, simply
use the  and  keys. To validate the value, press the  key. To exit the programme
without validating the value, press the

key.
This menu allows you to programme the desired production duration in PRG mode.
To change this value, simply use the  and  keys. To validate the value, press
the  key. To exit the programme without validating the value, press the

key.
Calibration of the ORP sensor is carried out in the same way as for the pH sensor.
But with a single measurement point.
Calibration is carried out using the 650mV solution supplied with the PHENIX device.
Ox Prod = REG
ORP limit = 660mV
Prod/24h= 08h
Ox Calibration
