FOLDING THE BIKE CARRIER
Lift one of the side arms (9) of the bike carrier.
Insert one of the bottom quick-release pins (1) into
the upper locking hole of the centre bracket.
Repeat the same procedure for folding the other
side arm.
Ensure that the bike carrier is not loaded with
bicycles.
Rotate the bottom quick-release pins (1) upwards
and remove the pins from the centre bracket.
