model no. 040-1193-8
KEY PARTS
KEY PARTS
A
B
D
E
J
F
G
H
I
K
C
L
PART NUMBER DESCRIPTION
A Rack arms
B Adjustable hub
C Adjustable hub knob
D Upper support leg
E Lower support leg
F Upper strap with top reversable hook
G
Side strap with hook
H Lower strap with hook
I 80" (2 m) cam buckle cargo strap (blue)
J Rubber bumper
K Bike cradle with anti-sway cage
L Cradle strap (included) (Qty. 9)
ASSEMBLY
4
5
The illustration shown below depicts the installation of the bike carrier on different vehicle styles. Install the bike
carrier according to the fitment configuration that best conforms to your vehicle.
Note: Carefully wipe down the rear surfaces of the vehicle with a damp cloth to remove dirt and debris to prevent
scratching of the vehicle.
Fit one end of the cradle strap (L) onto each
cradle (K) of the rack arm, and one end of a second
cradle strap to each anti-sway cage (1).
Note: Ensure that the cradle strap is fitted on the
single peg side of the cradle.
L
L
K
1
1
F
H
G
