Assembling and Dismantling of the Side Runner Frames
– Assemble the wire racks to the oven walls using the 2 screws (Figs. 15-17).
– Slide the tray and rack into the runners (Figs. 16-18). The rack must be fitted so that the safety catch,
which stops it sliding out, faces the inside of the oven.
– To dismantle, operate in reverse order.
Fig. 16
Fig. 18
Fig. 17
Fig. 15
