8
To remove and replace the grease
filters
• Touch the “On/+” key so the
moving panel raises to its full extent,
then isolate the power supply so it
stays raised.
• By pulling the two top corners of the
front panel (Fig. 2) at the same time,
it will be released and pivot toward
you.
• The grease filters can then be pulled forward and out.
• Replacement is a reversal of the removal procedure.
Please note:
Cleaning the grease filters in the dishwasher may lead to
discolouration. This is normal and does not constitute a fault with the
appliance.
Changing the charcoal filters (re-circulating only)
To ensure best performance of your extractor, you should replace the
charcoal filters every four to six months, depending on use.
To replace the charcoal filters
• Remove the grease filters as described opposite.
• The charcoal filters can then be lifted out and the replacements
placed in position.
• Replace the grease filters as opposite.
Pull
Fig. 2
