5
Fig. 3
Care and Maintenance
Changing the charcoal filter (re-circulating only)
When the display flashes alternating the speed selected with the letter F, the
charcoal filters must be replaced. After the charcoal filter has been replaced,
the electronic memory must be reset by touching key A for approximately
five seconds, until the letter F stops flashing.
To attach a new charcoal filter, first open the cover panels and the filters as
described above. Then offer up the charcoal filter into the frame as shown in
figure 3. Repeat with the other charcoal filter. Then replace the grease filters
and cover panels.
To attach a new charcoal filter, first remove the grease filters as described
above. Then offer up the charcoal filter to the side of the motor as shown in
figure 3 and turn it clockwise until it locks into place. Repeat with the other
charcoal filter on the other side of the motor. Then replace the grease filters
and cover panels.
