CDA FW381 User Manual

fig. 14
Installation
Fig. 12 - Aligning the decor door
Close the door and check the alignment with the other unit
doors. Adjust the decor door by screwing or unscrewing the
adjustment bolts for vertical adjustment and by the help of the
slots on the fixing bracket for other directions. Lock the screws
into place as shown in 10.2.
Fig. 13 - Fitting the decor door base fixings
With the appliance door open, remove the screws at the
bottom of the appliance door. Locate the decor door base
fixings (3) and screw the fixings to the appliance door and the
decor door.
Fig. 14 - Fitting the decorative cover
Fit the decorative cover (4) on the decor door fixing bracket.
fig. 12
fig. 13
10
10
8
1
3
4
