5
Controls and Use
1. Thermostat dial
The thermostat automatically keeps the internal temperature at a
constant level. The temperature is regulated by the thermostat dial,
located on the freezer control panel. To change the temperature,
turn the dial anti-clockwise from 1 (highest temperature) to 5 (coldest
temperature). We recommend that you start with the appliance set
to position 3.
Do not turn the dial beyond the maximum. To switch the freezer
o, turn the dial anticlockwise to the minimum position.
2.Super freeze button
This freezer is equipped with a super freeze function. This allows
the freezer compressor to run continuously and so freezes food
more quickly. To select this function, press the button briefly, the
super freeze indicator light (5) illuminates. To switch the function
o, press the button and hold it for three seconds, the indicator light
goes out again.
Note that this function will switch itself o automatically after 24
hours.
3.Power indicator light
This green light will illuminate when the freezer is switched on.
12
3
4 5
1 3 4 5 2
S
S
fig. 1
OFF
