CDA RC9300

27
Fig. 33
Stability bracket
We recommend a stability bracket is fitted to the cooker.
The type shown in fig. 33 can be purchased from most plumbers merchants and do
it yourself (D.I.Y.) shops.
Wall fixing
Floor fixing
Brackets
Existing slot
in rear of
cooker
Dotted line showing the
position of cooker when fixed
Dimension is in millimetres
3
Outline of cooker
backplate at the
engagement slot
