CDA RC9300 User Manual

33
Injectors replacement of top burners
Every cooker is provided with a set of injectors for the various types of gas.
Injectors not supplied can be obtained from the After-Sales Service.
Select the injectors to be replaced according to the table at page 35.
The nozzle diameters, expressed in hundredths of a millimetre, are marked on the
body of each injector.
To replace the injectors proceed as follows:
– Remove the grids and extract the burner bodies.
– Using a wrench, substitute the nozzle injectors “J” (Figs. 37 - 38) with those most
suitable for the kind of gas for which it is to be used (see “Table for the choice of the
injectors”).
The burners are constructed in such a way so as not to require the regulation
of the primary air.
J
J
Fig. 37 Fig. 38
Conversion to Natural Gas or to LPG
