Technical features
Input voltage 12 VAC/DC
Output 2 relays, N/O & N/C contact 3A /125V
Anti-triggering contact 500 mA 50 V ~ or =
Badge entry 500 programmable badges
Code entry 500 programmable codes, 5-digit PIN code
Master code 5-digit programmable code
Input 1 request-to-exit
Keyboard 12-digit keypad with built-in buzzer (audible signal)
Distance between the
second reader and the
DGPROX unit
minimum 24 inches (60 cm)
maximum 45 yards (50 meters)
(cable minimum 7 x 0.6 mm
2
AWG22)
Default values
Master code: 12345
Relay time delay: 1 second
Key-in keypad: 10 seconds
Alarm: Off
Audible signals
1 beep (long) Validation of data in programming mode: master code,
proximity badge or time delay.
Or access code validated
2 beeps (short) Accessing the programming mode
or exiting from the programming mode
4 beeps (short) incorrect mode, user number time delays entered
Visual signals
LED color Normal mode Programming mode
Green Door relay activated Code/Badge position empty
Red Alarm relay activated Code/Badge position busy
Orange Programming mode
Orange flashing Stand-by Data computing error
Request-to-exit
The request-to-exit push button PB1 operates relay RL1.
The LED turns green when the relay is activated.
Warning: Do not use a switching power supply because of radiation
interference, which may disturb the reading of the badges.
