DRUMFIT STATIC 6000 SEAT
5150
ENGLISH ENGLISH
1. PARTS AND COMPONENTS
Parts to be assembled of the exercise bike. Fig. 1
No. Quantity Description No. Quantity Description
1 1 Console 2 1 Handlebar stem
3 1 Front stabiliser 4 1 Pedal (L)
5 1 Pedal (R) 6 1 Main frame
7 1 Rear stabiliser 8 1 Side hand grips
9 1 Sliding rail 10 1 Adjustment knob
11 1
Backrest
bracket
12 1 Saddle
13 1 Backrest
Fixing elements for assembly. Fig. 2
Part Quantity Description
A 14 Plain washer ø8
B 10 Curved washer ø8
C 6 Pressure washer ø8
D 6 Cap nut M8
E 12 Allen screw M8*12
F 4 Allen screw M8*40
G 2 Allen screw M8*50
NOTE:
the graphics in this manual are schematic representations and may not exactly match the
device.
2. BEFORE USE
- This appliance is packaged in a way as to protect it during transport. Take the device out
of its box and remove all packaging materials. You can keep the original box and other
packaging elements in a safe place. This will help you prevent damage to the device when
transporting it in the future. In case the original packaging is disposed of, make sure all
packaging materials are recycled accordingly.
- Make sure all parts and components are included and in good conditions. If there is any
piece missing or in bad conditions, contact the ocial Cecotec Technical Support Service
immediately.
