Cedar Summit McKinley - Floor Assembly

17 support@cedarsummitplay.com
REV.
DWG. NO.
SIZE
SCALE:1:50 WEIGHT:
Details
SHEET 1 OF 5
SCALE:1:50 WEIGHT:
Floor Joist Prep
SHEET 2 OF 5
REV.
DWG. NO.
SIZE
SCALE:1:50
•See details
WEIGHT:
SHEET 3 OF 3
REV.
A
DWG. NO.
SIZE
Floor Joist ISO
A: From inside the assembly centre (2608) Floor Joist over pilot holes in (2622) End Panel Assembly and (2627)
SW Wall Panel, 5/8” down from the top of board then attach (2608) Floor Joist to each panel with 2 (S4) #8 x 3”
Wood Screws per end. (g.3.1, 3.2 and 3.3)
Step 3: Floor Assembly
Part 1
1 x Floor Joist 1-1/4 x 3 x 40-3/4”
2608
Fig. 3.2
Wood Parts
Fig. 3.1
2608
2627
2608
Top View
Fig. 3.3
Hardware
4 x #8 x 3” Wood Screw
x 2 per
side
S4
2608
5/8”
2622
and
S4
S4
2627
2622
2622
S4
