SCALE:1:50
•Attach Chimney to roof using 2- #6 x 5/8" Pan Screws
WEIGHT:
SHEET 4 OF 5
REV.
DWG. NO.
SIZE
Roof Panel CONNECT A2
SIZE
SCALE:1:50
WEIGHT:
Details
SHEET 1 OF 5
REV.
DWG. NO.
16 x #12 x 3/4” Pan Screw
(1/4” at washer)
Hardware
Fig. 25.2
2617
S8
Fig. 25.1
2617
2617
Step 25: Attach Peak Detail
A: Attach 1 Peak Detail to the inside of the (2617) Roof Supports on each side of the Roof Assembly with 8 (S8)
#12 x 3/4” Pan Screws (with 1/4” at washer) per Peak Detail. (g. 25.1 and 25.2)
Other Parts
2 x Peak Detail
Peak Detail
Roof Assembly
Peak Detail
2617
Peak Detail
S8
S8
To Next Page
