19
1. Attach the electrodes to the cables.
If carbon rubber electrodes are being
used, spread on an even layer of gel.
Wash and dry the skin well before
attaching the electrodes.
2. Turn the stimulator on with .
If you wish to use the same settings
as last time you stimulated, you can
start stimulation directly by setting
the desired amplitude with for
each channel.
3. To choose program press for
each channel until the wanted
program is shown. NOTE!This can
only be done when both channels are
set to 0.0 mA.
4. Start stimulation by selecting the
desired amplitude with for each
channel.
NOTE!
20 seconds after the amplitude has been
set the key lock is automatically
activated. Deactivate the key lock by
pressing one of the buttons.
Note with mixed frequency TENS
(P4 and P5):
One amplitude for each frequency is
being set, to make the stimulation
comfortable. Instructions: First set one
amplitude for conventional stimulation
(15 Hz or 80 Hz) and then, when the
stimulator after 3 seconds switches over
to burst stimulation (2 Hz), set the
amplitude for this frequency. mA is lit
with conventional stimulation and
blinking with burst stimulation.
Program: Stimulation form: Frequency: Pulse duration: Timer:
P1 Conventional TENS 80 Hz 180 µs ---
P2 Burst TENS 2 Hz 180 µs ---
P3 Modulated pulse duration TENS 80 Hz 70–180 µs ---
P4 Mixed frequency TENS 15 Hz/2 Hz 180 µs ---
P5 Mixed frequency TENS 80 Hz/2 Hz 180 µs ---
P6 Nausea treatment 10 Hz 180 µs ---
P7 Facial treatment 80 Hz 60 µs ---
P8 Conventional TENS 80 Hz 180 µs 30 minutes
P9 Burst TENS 2 Hz 180 µs 30 minutes
