Celestron Advanced VX 91519 - Advanced VX Mount

6 I
Advanced VX Mount (Advanced VX with 8” Edge HD Optical Tube Shown)
1 Optical Tube
2 Advanced VX Equatorial Mount
3 ,ATITUDE!DJUSTMENT3CALE
4 4RIPOD#ENTER,EG"RACE!CCESSORY4RAY
5 Tripod
6 Counterweight
7 #OUNTERWEIGHT"AR
8 Hand Control
9 Control Panel
10 R.A. Motor Housing
11 Dec Motor Housing
#/.42/,0!.%,
A Power Port
" DEC Motor Port
C Power Switch
D Auxiliary Ports
E Hand Control Port
F Auto Guider Port
"
1
11
10
7
6
4
5
2
9
3
8
D
C
E
F
A
