1 2
3
4
5
6
7
8
9
10
11
12
Figure 1-1 AstroMaster 90AZ Refractor
(AstroMaster 70AZ refractor similar)
1. Objective Lens 7. Pan Handle
2. Telescope Optical Tube 8. Accessory Tray
3. Star Pointer Finderscope 9. Tripod
4. Eyepiece 10. Azimuth Lock
5. Diagonal 11. Alt-Az Mount
6. Focus Knob 12. Dovetail Mounting Bracket
4
