Figure 1-2 AstroMaster 114 AZ Newtonian
1. Star Pointer Finderscope 7. Azimuth Lock
2. Eyepiece 8. Accessory Tray
3. Tube Ring 9. Tripod
4. Telescope Optical Tube 10. Alt-Az Mount
5. Primary Mirror 11. Dovetail Mounting Bracket
6. Pan Handle 12. Focus Knob
