Figure 1-1 AstroMaster 90 EQ Refractor
1. Telescope Optical Tube 9. Latitude Adjustment Screw
2. Dovetail Mounting Bracket 10. Accessory Tray
3. RA. Setting Circle 11. Tripod
4. Star Pointer Finderscope 12. Counterweight Bar
5. Eyepiece 13. Counterweights
6. Diagonal 14. Equatorial Mount
7. Focus Knob 15. Dec. Slow Motion Cable
8. R.A. Slow Motion Cable 16. Objective Lens
1
2
3
4
5
8
9
7
6
10
11
12
13
14
15
16
