Celestron CGX - Overview

6 | ENGLISH
Overview
Figure 1.1 Overview
8 mm Allen Wrench
(Located under carry handle)
Dovetail Lock Knobs
Carry Handle
DEC Clutch Lock Lever
R.A. Clutch Lock Lever
Counterweight Shaft
Counterweights
Counterweight Stop Nut
Tripod
Accessory Tray
Hand Control
Dovetail Saddle
Aux 1 & Aux 2 Ports for Hand Control and Accessories
12VDC 4A Power Input
Altitude Lock Knobs (One on each side)
Altitude Adjustment Knob
Azimuth Adjustment Knobs
Carry Handle
On/Off Switch
See fi gure 1.2
8 mm Allen Wrench
(Located under carry handle)
Carry Handle
