cellarking CX - Part Numbers; Unit Combinations; CX(E) Options; Dimensions and Weights

3/23
55908014-06
PART NUMBERS
MODEL
CX 30 CX 40 CX 50 CX 70
PART NUMBER
55900001 55900002 55900003 55900004
MODEL
CXE 30 CXE 40 CXE 50 CXE 70
PART NUMBER
55900017 55900016 55900015 55900014
MODEL
CKC 20 1ph CKC 30 1ph CKC 50 1ph CKC 80 1ph CKC 80 3ph
PART NUMBER
55023720 55023730 55023722 55023723 55023724
MODEL
CKR 30 1ph CKR 50 1ph CKR 80 1ph
PART NUMBER
56000001 56000002 56000003
INDOOR UNIT OUTDOOR UNIT INDOOR UNIT OUTDOOR UNIT
CX(E) 30 CKC 20 CX(E) 30 CKR 30
CX(E) 40 CKC 30 CX(E) 50 CKR 50
CX(E) 50 CKC 50 CX(E) 70 CKR 80
CX(E) 70 CKC 80
OPTIONAL KITS
PART NUMBER DESCRIPTION
55900700 3kW heater (CX only)
55900701 Digital temperature display (CX only) std on CXE
55900702 De-ice thermostat (CX only)
55900709* Extended pipe run CX 30/40/50 only
55900710* Extended pipe run CX 70 only
55900715 3kW heater (CXE only)
* When matched with CKC outdoor units
MODEL UNPACKED PACKED
CX(E) HEIGHT WIDTH DEPTH WEIGHT HEIGHT WIDTH DEPTH WEIGHT
30
483 845 320 18 530 950 370 21
40
483 845 320 20 530 950 370 23
50
483 845 320 20 530 950 370 23
70
483 845 320 23 530 950 370 26
WEIGHT WEIGHT
CKC HEIGHT WIDTH DEPTH
1Ph 3Ph
HEIGHT WIDTH DEPTH
1Ph 3Ph
20
560 900 300 46 - 625 980 340 48 -
30
560 900 300 53 - 625 980 340 55 -
50
560 1000 300 64 - 730 1080 340 66 -
80
560 1000 300 66 64 730 1080 340 68 66
CKR HEIGHT WIDTH DEPTH WEIGHT HEIGHT WIDTH DEPTH WEIGHT
30
525 795 255 39 580 940 330 41
50
585 850 295 48 680 990 410 50
80
680 870 310 62 680 990 415 64
CX(E) OPTIONS
DIMENSIONS & WEIGHTS
UNIT COMBINATIONS
