cellarking CX - CX(E) Dimensions

7/23
55908014-06
(Wall mounted)
FRONT VIEW
(Wall mounted)
REAR VIEW
(Ceiling Mounted)
TOP VIEW
(Ceiling mounted)
SIDE VIEW
X
2Z
1Z
X
(Wall mounted)
SIDE VIEW
= Liquid / Expansion
2
Z
= Suction 1
Z
X = Interconnecting Wiring
20
483
FOR SIDE ACCESS
MIN. 500
96
320
120
888 (Fixing centers)
124
888
845
70
422.5
124 (Fixing centers)
39
39
60
17.5
17.5
MIN.
120
36
215
75
140
65 TYP.
35
96
CONDENSATE DRAIN 22mm OD
CX
(
E
)
DIMENSIONS
