GENERAL
INDEX
CONTENTS PAGE
PART NUMBERS, OPTIONS, UNIT COMBINATIONS, DIMENSIONS & WEIGHTS 3
PERFORMANCE DATA & AIR FLOW 4
SOUND POWER AND SOUND PRESSURE LEVELS 5
ELECTRICAL DATA 6
CX(E)
DIMENSIONS 7
INSTALLATION: CONTENTS & PIPEWORK 8
ELECTRICAL: FUSES & WIRING DIAGRAMS 9
CKC
INSTALLATION: DIMENSIONS 10
PIPEWORK 11
ELECTRICAL 12
REFRIGERANT 13
CKR
INSTALLATION: DIMENSIONS 15
PIPEWORK 16
ELECTRICAL 18
REFRIGERANT 19
COMPONENT IDENTIFICATION
CX(E) UNITS 20
CKC UNITS 21
CKR 30 22
CKR
50 23
CKR
80 24
1. TEV Ltd recommend that personnel working on this equipment be skilled and fully conversant with
the appropriate Air Conditioning, Refrigeration and Electrical practices and have sound knowledge
of current Industrial Safe Working practices.
2. CX(E) models are electromechanical / Electronic control units that use R407C refrigerant; they
provide cooling within the range of 2.8 – 6.8 kW. These units are matched with CKC and CKR
outdoor units to complete a system.
CX(E) units are fitted with an expansion assembly, allowing the use of a liquid line. This can be
transferred to the outdoor unit (CKC only), when an expansion line is required to accommodate
longer pipe runs.
3. These units contain live electrical components, moving parts and refrigerant under pressure.
Always site out of reach of children and protect from vandalism.
4. The data plate only gives information for the CX(E) unit. For system details add input power and
current of indoor and outdoor unit, including any heater load.
