INSIDETHECELLAR
(TheColdSide‐atthefrontofthecoolingunit)
EvaporatorAirIntake
. CellarProcoolingunitsshouldbemountedatthehighestpointinsidewine
cellars,sothatwarmair–whichrises–willbethefirsttopassovertheevaporatorcoils,whichare
located behind the grill on the face of the cooling unit.  When the warm air passes across the
evaporatorcoils,heatisremovedtheair,andtheresultingcoldairisexhaustedintothecellar.To
ensureproperairflow,minimumclearanceof12”isrequiredinfrontofthecoolingunit.

EvaporatorAirExhaust.  Coldairisexhaustedatthetopfrontofthecoolingunit.BecauseCellarPro
coolingunitsarelocatedatthehighestpointinsidewinecellars,thecoldairexhausteventuallywill
droptothebottomofthecellar.Toensureproperairflowandreducetemperaturestratification
insidethecellar,thespaceinfrontofthecoldairdischargeshouldbeclearofanyobstructions,
includingwinebottles,wineracks,etc.
Ducting.Weofferductkitsthatallowtheevaporatorairintakeandexhausttobeductedupto50
equivalentfeeteachwithaminimumof8”diameterinsulatedductingfromstarttofinish.Our
cold‐sideductkits(soldseparately)attachtothefrontofthecoolingunitandMUSTbeusedwhen
ductingourcoolingunits.TheHIGHfanspeedmustalwaysbeusedwhenductingthecoolingunit.
UsingcustomductadaptersinsteadoftheCellarProductkits,reducingductingbelow8”diameter,
usingfansatlowormediumfanspeed,and/orexceedingtheequivalentlengthlimitswillimpair
theperformanceandlongevityoftheunitandvoidthemanufacturer’swarranty.
 PowerRequirements
CellarProcoolingsystemsshouldbepluggedintoadedicatednon‐GFIoutletconnectedtoa15‐
ampcircuit.Thecoolingunitusesapproximately8.9(3200VS)and10.5(4200VS)ampsduringits
“on”cycle.
A number of variables, including the minimum set point, the temperature in the ambient
environment,theinsulationofthecellar,andthethermalmassinsidethecellar,willaffectthe
cooling unit’s runtime. It is normal for the cooling unit to run up to 75 percent of the time to
maintainproperconditionsinsidethecellar.
Selectapowerreceptacle(FrontorRear)andplugtheprovidedpowercordintothatreceptacle.
Plugtheotherendofthepowercordintoadedicated15ampcircuit.Asurge‐protectedcircuitis
recommended.Setthepowerselectorswitchtoenergizetheappropriatereceptacleused(Front
orRear).
ThepowercordprovidedfortheindoorVSiunitsisapprovedforindooruseonly,whilethepower
cordfortheoutdoorVSxunitsmaybeusedbothforindoororoutdoorapplications.
 
