USB Connection Terminal
1. Purpose: USB device connection or power supply.
2. USB Connector: Standard USB Mini-B type
3. Interface Specication: Compliant with USB HID class
specication version 1.11
4. Input Power: 0.5A 5V dedicated DC adapter or USB Bus
power from a host device.
Bluetooth Connection Switches
1. Bluetooth HID Switch (Top)
2. Bluetooth SPP Switch (Bottom)
5. Using the Projection Keyboard
This product is used as a keyboard and mouse via Blue-
tooth HID and USB HID connection.
5.1 Connecting via USB HID
This device is compatible with all USB HID capable oper-
ating system.
USB HID connection allows plug-n-play, without install-
ing a separate driver.
1) Connect Magic Cube™ and host device using supplied
USB cable. Host device must support USB HID. Note:
Most Windows devices support USB HID.
2) Turn on Magic Cube™.
3) Green LED indicates proper connection. If LED indi-
cates blue, please check the connection.
