WALL-MOUNTED ELECTRIC FIREPLACE/HEATER
BFM EUROPE LTD Page 9
OPERATING INSTRUCTIONS
 The Fireplace/Heater Unit
On the top right side plate of the fireplace/heater unit is the control panel. This panel contains the
buttons to properly operate the fireplace/heater unit. Refer to below figure for placement of the control
buttons.
The upper segment of the control panel, (1), is the Main Power button. As the name infers, the Main
Power button controls the overall power to the fireplace/heater unit. Pressing the button once turns
power on to the entire unit, and pressing the button again will turn power off to the entire unit. If you
find that none of the other buttons appear to work, check to make sure that Main Power is turned on to
the unit.
The next segment, (2) is the Flames Control button. Like the Main Power button it controls the
flames and fuel bed lights of the electric heater unit. Pressing the button once turns the flames on and
the fuelbed lights up orange, a second press of the button will keep the flames on and change the
fuelbed to blue. Further button presses will cycle through the options listed below.
BUTTON PRESS
Flame State
Fuel bed Colour
1
st
press
ON
Orange
2
nd
press
ON
Blue
3
rd
press
ON
Orange & Blue
4
th
press
ON
Automatically Display
5
th
press
OFF
OFF
The next segment, (3),L_heat Control, is a low heat button for the heater. Pressing the button
once ,the low heat function is on, and pressing the button twice ,the low heat function is off.
The next segment, (4), H_heat Control , is a high heat button for the heater. Pressing the button once ,the
high heat function is on, and pressing the button twice ,the high heat function is off.
