emerald Quick Installation Guide
3
1.1.2 UL-294 grading
The emerald terminal has been rated according to the UL-294 grading system and is outlined
in Table 2:
1.1.3 Terminal dimensions
Figure 2 Illustration of emerald including dimensions
Dimensions of the emerald terminal:
Length: 157mm (6.2”) Width: 109mm (4.3”)
Depth (bottom): 49mm (1.9”) Depth (top): 28mm (1.1”)
Feature Grading
Destructive attack 1
Line security 1
Endurance 4
Standby power 1
Table 2: UL-294 grading
