LCD Display (“ ”)See figure C
1- Laser active
2- Reference level (front)
3- Reference level (rear)
4- Variable measuring functions
Area measurement
Volume measurement
Indirect measurement
Indirect (second) measurement
5- Single distance measurement
6- Battery status
7- Historical memory
8- Instrument error warning
9- Continuous measurement & Max and Min measurement
10- First value display line
11- Second value display line
12- Summary line for last measure or calculation result
Laser Distance Meter User Manual
7
Figure C
1
2
3
4
56 7 8
10
11
12
9
