Cembre B500ND - General Characteristics

5
(1)
Directive 2006/42/EC, annexe 1, point 1.7.4.2 letter u
L
pA
= weighted continuous acoustic pressure level equivalent.
L
pCPeak
= maximum value of the weighted acoustic displacement pressure at the work place.
L
WA
= acoustic power level emitted by the machine.
(2)
Directive 2006/42/EC, annexe 1, point 2.2.1.1
Weighted root mean square in frequency of the acceleration the upper limbs are exposed to for each biodynamic
reference axis. Tests carried out in compliance with the indications contained in EN ISO 5349-1/2 Standard, and under
operating conditions much more severe than those normally found.
1. GENERAL CHARACTERISTICS
ENGLISH
B500ND B500NDE B500NDT B500NDA
Application range
suitable for installing electrical compression connectors on
conductors up to 300 mm
2
(600 MCM)
Rated crimping force
kN (US sh. ton) 60 (6.75)
Minimum operating pressure bar (psi) 661 (9587)
Dimensions mm (inches) 396 x 136 x 81 (15.6 x 5.3 x 3.2)
Weight with battery kg (lbs) 3,15 (6.9)
Motor V DC 18
Operating temperature °C (°F) -15 to +50 (+5 to +122)
Recommended oil TOTAL DIEKAN 1640 or equivalents
Operating speed
twin speed operation and automatic switching from a rapid
advancing speed of the ram to a slower, more powerful
crimping speed
Safety maximum pressure valve
Rechargeable battery V / Ah / Wh 18 / 2.0 / 36
Type CB1820L (Li-Ion)
Weight kg (lbs) 0,4 (0.9)
Battery charger
ASC30-36
Input
type
EU
27044000
UK
27045000
AUS/NZ
27047000
USA/CAN
27046000
V / Hz 220 - 240 / 50 - 60 115 / 60
W85
Acoustic noise
(1)
L
pA
dB (A) 67,7
L
pCPeak
dB (C) 89,2
L
WA
dB (A) 74,2
Vibration
(2)
m/s
2
a
hv
0,724
