Page 2 For technical questions, please call 1-800-444-3353. Item 60704
Specifications
Input
Voltage
12 VDC Nominal
(11-15 VDC)
Wire Gauge
7 AWG (up to 6 ft.)
5 AWG (up to 10 ft.)
Internal Fuses 40 A x 3
Input Fuse Rating 120 A
Output
Continuous 1000
Surge 2000
Receptacles
2 AC outlets,
1 USB port
Waveform Modified Sine Wave
Voltage Range 115 ±10V~
Frequency 60 ±2Hz
Ground Wire Gauge 8 AWG
No Load Current
(Switch on)
0.8 A
Maximum efficiency >85%
Full load efficiency >80%
Over voltage Shutdown 15.75 ±0.75 V
Low voltage alarm 10.5 ±0.5 V
Low voltage shutdown 10 ±0.5 V
Thermal Shutdown 149 ±9 °F
Note: Battery charge level, wire length and
other factors will effect performance.
WARNING SYMBOLS AND DEFINITIONS
This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
Obey all safety messages that follow this symbol to avoid possible injury or death.
Indicates a hazardous situation which, if not avoided,
will result in death or serious injury.
Indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
Indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury.
Addresses practices not related to personal injury.
