Page 5For technical questions, please call 1-800-444-3353.Item 66817
Specifications
Input Voltage 12 VDC (nominal)
Output Voltage 115 V~ / 60 Hz
Continuous Power 750 W
Surge Power 1500 W
Operating Conditions 32° - 104° F
Receptacles
Two 3-prong grounded polarized AC outlets
One 5 VDC 500mA USB outlet
Fuse Type
One 35 Amp Internal Blade-type Fuse
(professional replacement only)
Overall Dimensions 9-1/4" L x 5-1/4" W x 2-1/2" H
3069523
Amp Load
5 10 20 30 40 50 60 70 80 90 100
Distance (yards)
1
16 14 12 10 10 10 8 8 8 6 6
2
16 14 12 10 10 8 8 8 6 6 6
3
16 14 10 10 8 8 6 6 6 6 4
4
16 14 10 10 8 8 6 6 6 4 4
5
16 14 10 8 8 6 6 6 4 4 4
6
14 14 10 8 6 6 6 4 4 4 4
7
14 14 10 8 6 6 6 4 4 4 4
8
14 12 8 8 6 6 4 4 4 4 4
9
14 12 8 8 6 4 4 4 4 4 2
10
14 12 8 8 6 4 4 4 4 2 2
Amp Load
5 10 20 30 40 50 60 70 80 90 100
Distance (yards)
1
16
14
12 10 8
62
83
10
6
4
4
5
8
6
4
6
14
7
8
12 49
2
10
Output Waveform
1.
Modified
Sine
Wave
(MSW)
This inverter’s output is a Modified Sine Wave.
Power from most electric utilities is a Sine Wave.
Note: Only multimeters identified as “TRUE RMS“
will read Modified Sine Wave voltage accurately.
2. Modified Sine Wave (MSW) power is suitable
for most AC devices and power supplies used in
electronic equipment, transformers, and motors. Do
not use to power sensitive devices such as medical
equipment or computers. Some audio equipment may
perform poorly if run on Modified Sine Wave power.
3. Sine Wave inverters provide power that is identical
to, or even better than, the power supplied by
your power company. Motors start easier and run
cooler under Sine Wave power. Certain devices,
such as laser printers, variable speed motors and
digital clocks, require sine wave power to operate
properly. Sine wave inverters are typically more
expensive for their capacity than other inverters.
