Page 10Item 96308
For technical questions, please call 1-888-866-5797.
Resistance Measurement
Measure circuit resistance up to 2000Ω.
WARNING! TO PREVENT SERIOUS
INJURY: To prevent electric shock, turn off
all power and fully discharge capacitors on
the circuit under test before measuring.
Note: When measuring Ohms, start with the
lowest range if the resistance is unknown.
1. Plug black test lead into COM Jack.
Plug red test lead into INPUT Jack.
2. Turn Rotary Switch to
2000Ω or 200kΩ.
3. Carefully touch exposed
conductors with tips of probes.
4. Read measured resistance on Display.
Note: Meter will beep if measured
resistance is less than approximately
50Ω in 2000Ω position.
5. When testing is complete, turn
Rotary Switch to OFF, remove
Test Leads and store with Meter.
Note: Sometimes resistor value and
measured resistance differ. This is due
to the Meter’s output test current going
through all possible paths between leads.
Note: For low resistance measurements,
short the test leads and record the
resistance displayed. Then connect to
the circuit and subtract the recorded
resistance from the measurement
for the most accurate results.
Record Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only, and are not
available individually as replacement parts. Refer to UPC 193175514301.
