Page 7SKU 97245 For technical questions, please call 1-800-444-3353.
Functions
This tool is useful for detecting metal embedded in nonmetallic materials.
For example, you can detect nails in wood prior to running a board through a
planer, jointer or shaper. This will help protect expensive knives and blades from
damage.
This tool will detect metal at a range of approximately 1-1/4” to 2-1/2” depending
on materials being tested and the sensitivity setting used.
OPERATING INSTRUCTIONS
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the
beginning of this manual including all text under subheadings therein
before set up or use of this product.
Tool Set Up
To increase accuracy, it is useful to test this detector on a sample piece prior to
actual use. This provides the chance to adjust sensitivity prior to critical work. A
clockwise rotation will increase the sensitivity.
General Operating
Instructions
Press and hold the Power
Switch into the ON position.
With the power switch in the
ON position, the LED light
will illuminate the detec-
tion area or scanned area.
Please note: Brightness
may vary due to workplace lighting.
Move the wand portion of the tool over the work material. When metal is detect-
ed, the alarm will sound.
When work is completed, release the Power Switch button to turn off the tool.
Clean, then store the tool in its carrying pouch, indoors, and out of children’s
reach after use.
1.
2.
1.
1.
2.
3.
4.
LED Spot Light
Power Switch
Sensitivity Switch
Wand
