CENTR 1 - Step 7 Assembly

Pg. 17V07122023-C5

22222323
1616 3636
3737
3535
35
36
16
37
2223
(35) BOLT, M6 X 1 X 75, SH, BZ, .
(36) WASHER, FLAT, 6.4 X 12 X 1.6, BZ, .
(37) NUT, M6 X 1,LOCK, BZ, .
(16) BOLT, M6 X 1 X 60, SH, BZ, .
(36) WASHER, FLAT, 6.4 X 12 X 1.6, BZ, .
(37) NUT, M6 X 1,LOCK, BZ, .
HARDWARE REQUIRED:
